472,24 TL + KDV
Stok Durumu:
Var
(10 Adet)
Not
:
Aynı Gün Kargo
15’e kadar aynı gün kargo
Worldwide
Shipment
Next Day
Shipment
Kampanya
{{CMP.TITLE}}
{{CMP.DESCRIPTION}}
- Ürün Özellikleri
- İade ve Teslimat
- Ödeme Seçenekleri
- Yorumlar (0)
- Beni Ara
- Ek
-
RF Parameter Value Remark Working frequency 850~930 MHz - Transmitting power 22 dBm Max. Power (160mW) Receiving sensitivity -147 dBm - Air data rate 0.018k~300kbps - Test distance 7000m In open and clear air, with maximum power, 5dBi antenna gain, height of 2m Hardware Parameter Value Remark Size 14 * 20 mm Antenna type IPEX / Stamp hole Communication interface SPI Package SMD Electronic parameter Min. Typ. Max. Unit Condition Power supply 1.8 3.3 3.7 V Communication level 1.8 3.3 3.7 V Transmitting current 114 119 124 mA 22dBm（160mW） Receiving current 4.8 5 5.9 mA Sleep current 150 185 200 nA Operating temperature -40 20 85 ℃ Operating humidity 10 60 90 % Storage temperature -40 20 125 ℃
