🔧 Hardware Specifications
-
Dimensions: 90.5 mm × 94.5 mm × 22.7 mm
-
Power Supply: DC 5V / 2A adapter
-
Connectors:
-
Ethernet (RJ-45)
-
RS-232C serial port
-
Reset button
-
-
Included Accessories:
-
2.5dBi dipole antenna (SMA type)
-
Serial cable
-
Crossover network cable
-
Data CD (manual, hardware & software materials)ManualsLib+3manualzilla.com+3FCC ID+3TME+6FCC ID+6manualmachine.com+6manualzilla.com+2manualmachine.com+2FCC ID+2
-
📡 Wireless Specifications
-
Standard: IEEE 802.11b/g
-
Frequency Range: 2.412–2.485 GHz
-
Data Rates: 54 Mbps to 1 Mbps
-
Modulation:
-
802.11b: DSSS (CCK, DQPSK, DBPSK)
-
802.11g: OFDM (64QAM, 16QAM, QPSK, BPSK)
-
-
Output Power:
-
802.11b: 16 dBm @ 11 Mbps
-
802.11g: 14 dBm @ 6–54 Mbps
-
-
Receive Sensitivity:
-
802.11b: -65 dBm @ 11 Mbps
-
802.11g: -76 dBm @ 54 Mbpsmanualmachine.com+2FCC ID+2manualzilla.com+2manualmachine.com+1FCC ID+1
-
🔐 Security Features
-
Encryption:
-
WEP (64/128-bit)
-
WPA/WPA2 (AES/TKIP)
-
-
Authentication: 802.1x (RADIUS)WIZnet+4FCC ID+4manualzilla.com+4ManualsLib
🔄 Operating Modes
-
Access Point
-
Client
-
Gateway
-
Serial to Wireless LAN
-
Ethernet to Wireless BridgingWIZnet+6manualzilla.com+6manualmachine.com+6manualmachine.com+4FCC ID+4ManualsLib+4manualzilla.com+2manualmachine.com+2FCC ID+2
📡 Network Protocols
-
TCP/IP Stack:
-
ARP, UDP, TCP, Telnet, ICMP, IGMP
-
DHCP, PPPoE, BOOTP, HTTP, TFTPManualsLib+1FCC ID+1
-
⚙️ Additional Features
-
Data Streaming: Up to 25 Mbps
-
Compliance: RoHS, CE, FCC, KCC certified
-
Mounting: Compact design suitable for embedded applicationsFCC ID+2manualzilla.com+2manualmachine.com+2manualzilla.com+2FCC ID+2manualmachine.com+2
For detailed configuration and setup instructions, you can refer to the WIZ6000 User Manual.
-
