1.761,70 TL + KDV
Stok Durumu:
Var
(20 Adet)
Not
:
Aynı Gün Kargo
12.30’a kadar aynı gün kargo
Worldwide
Shipment
Next Day
Shipment
Kampanya
{{CMP.TITLE}}
{{CMP.DESCRIPTION}}
- Ürün Özellikleri
- İade ve Teslimat
- Ödeme Seçenekleri
- Yorumlar (0)
- Beni Ara
- Ek
-
[Frequency]：410~441MHz
[Power]：20dBm
[Distance]：3.0km
[Interface]：RS232/RS485
[Weight]：130±5g
RF Parameter Value Remark Working frequency 410~441 MHz Default: 433MHz Transmitting power 20 dBm About 100mW Air data rate 2.4k~19.2kbps Default: 2.4kbps Test distance 3000 meters In open and clear air, with maximum power, 5dBi antenna gain, height of 2m,air data rate: 2.4kbps Hardware Parameter Value Remark Size 82 * 62 * 25 mm Without SMA-K Antenna type SMA-K - Communication interface RS232 / RS485 Standard DB9 Hole / 3.81 connecting terminal Baud rate 9600 Baud rate: 1200~115200 Buffer 512 bytes buffer Automatically sub-packaging with 197 bytes per package Electronic parameter Min. Typ. Max. Unit Condition Power supply 8 12 28 V - Transmitting current 330 367 403 mA 20dBm（100mW） Stand-by current 19 21 23 mA - Operating temperature -40 20 +85 ℃ - Operating humidity 10 60 90 % - Storage temperature -40 20 +125 ℃ -
