Teklif İsteyiniz
130,13 TL + KDV
Stok Durumu:
Yok
Not
:
Aynı Gün Kargo
15’e kadar aynı gün kargo
Worldwide
Shipment
Next Day
Shipment
Kampanya
{{CMP.TITLE}}
{{CMP.DESCRIPTION}}
- Ürün Özellikleri
- İade ve Teslimat
- Ödeme Seçenekleri
- Yorumlar (0)
- Beni Ara
- Ek
-
Limit Parameters Main Parameters Value Remarks Min. Max Voltage supply（V） 0 3.6 Voltage over 3.6V will causepermanent damage to module Blocking power（dBm） - 10 Chances of burn is slim when modulesare used in short distance Working temperature（℃） -40 85 - Operating parameter Main Parameters Value Remarks Min. Typical Max Operating voltage（V） 2 3.3 3.6 ≥3.3 V ensures output power Communication level（V） - 3.3 - For 5V TTL, it may be at risk ofburning down Operating temperature（℃） -40 25 85 Industrial design Operating frequency（GHz） 2.4 - 2.525 Support ISM band TX Current(mA) 12.5 13 13.5 Instant power consumption RX current（mA） 11.5 12 12.5 - Sleep current（μA） - 1 - Software is shut down Max Tx power（dBm） 4.5 5 5.5 set as 0dBm via software, with PA Receiving sensitivity（dBm） -92 -93 -94 Air data rate is 250kbps Air data rate（bps） 250k 250k 2M Controlled by user's programming Main parameter Description Remarks Distance 200m in open and clear air, at height of 2.5m，air data rate:250kbps FIFO 32 Byte Max packet length per time Crystal Frequency 16MHz - Modulation GFSK - Package SMD - Connector half hole 1.27mm - Communication interface SPI 0-10Mbps Size 12 * 19mm with PCB antenna Antenna PCB 50 ohm impedance
