EBYTE

4dBm.nRF52832. 0.1km. 2.379~2.496GHz

Ürün Kodu : E73-2G4M04S1A
Yorumlar
177,75 TL + KDV
Stok Durumu:
Var (6 Adet)
Not
:
Aynı Gün Kargo 15’e kadar aynı gün kargo
Worldwide Shipment
Next Day Shipment
Kampanya

{{CMP.TITLE}}

{{CMP.DESCRIPTION}}

  • Ürün Özellikleri
  • İade ve Teslimat
  • Ödeme Seçenekleri
  • Yorumlar (0)
  • Döküman
  • Beni Ara
  • Ek
  • RF Parameter Value Remark
    Working frequency 2379~2496 MHz Default:  2.4GHz (32MHz oscillator)
    Transmitting power 4 dBm About 2.5mW
    Receiving sensitivity -95 dBm Air data rate: 1Mbps
    Air data rate 1Mbps, 2Mbps Default: 1Mbps
    Test distance 100m In open and clear air, with maximum power, 5dBi antenna gain, height of 2m,
    air data rate: 1Mbps
    Hardware Parameter Value Remark
    IC nRF52810-QFAABB/QFN48 -
    FLASH 512 KB -
    RAM 64 KB -
    Core ARM® Cortex™ -M4F -
    Size 17.5 * 28.7 mm -
    Antenna type PCB / IPEX -
    Communication interface SoC -
    Package SMD -
    Electronic parameter Min. Typ. Max. Unit Condition
    Power supply 1.8 3.3 3.6 V ≥3.3 V ensures output power
    Communication level - 3 - V For 5V TTL, it may be atrisk of burning down
    Transmitting current - 18 - mA Instant power consumption
    Receiving current - 13 - mA -
    Sleep current - 2 - μA Software is shut down
    Operating temperature -40 - 85 Industrial design
    Operating humidity 10 - 90 % -
    Storage temperature -40 - 125 -
