EBYTE

GPRS , 30~33dBm, RS485/RS232, 82*84*25mm

Ürün Kodu : E840-DTU (GPRS-03)
Yorumlar
345,82 TL + KDV
Stok Durumu:
Yok
Teklif İsteyiniz Stoklara düşünce haber ver
Not
:
Aynı Gün Kargo 15’e kadar aynı gün kargo
Worldwide Shipment
Next Day Shipment
Kampanya

{{CMP.TITLE}}

{{CMP.DESCRIPTION}}

  • Ürün Özellikleri
  • İade ve Teslimat
  • Ödeme Seçenekleri
  • Yorumlar (0)
  • Beni Ara
  • Ek
  • Value Description
    Support Band Quad Band: GSM850, EGSM900, DCS1800, PCS1900
    Module automatically searches for frequencies
    Band selection can be set by AT command
    Compliant with GSM Phase 2/2+
    GPRS connection characteristic GPRS multi-slot class 12 (default)
    GPRS multi-slot class 1~12 (configurable)
    GPRS mobile station class B
    GPRS data feature GPRS data downstream transmission: up to 85.6kbps
    GPRS data upstream transmission: up to 85.6kbps
    Encoding format: CS-1, CS-2, CS-3 and CS-4
    Support for PAP (Password Authentication Protocol) protocols commonly used for PPP connections
    Support is usually used for CHAP (Interrogation Handshake Authentication Protocol) protocol
    Embedded protocol: TCP/UDP/FTP/PPP/HTTP/NTP/MMS/SMTP/PING, etc.
    Support for unstructured supplementary data services (USSD)
    Value Description
    Antenna SMA
    Data interface RS485 / RS232
    Baud rate 1200bps ~115200bps,default:115200bps
    TX power Class 4 (2W): GSM850  and EGSM900
    Class 1 (1W): DCS1800  and PCS1900
    AT command format Ebyte general AT command
    3GPP frequency 1 Timeslot 2 Timeslot 4 Timeslot
    CS-1 9.05kbps 18.1kbps 36.2kbps
    CS-2 13.4kbps 26.8kbps 53.6kbps
    CS-3 15.6kbps 31.2kbps 62.4kbps
    CS-4 21.4kbps 42.8kbps 85.6kbps
