HELTEC

HT-M02 Edge LoRaWan Gateway

Ürün Kodu : HT-M02
Yorumlar
Paylaş:
Fiyat Alarmı
32.788,86 TL + KDV

HT-M02 Edge LoRa Gateway is a part of the “Heltec LoRa“ series, with the following features:

  • CE & FCC Certificate
  • Integrated Linux Operating System (4.14 Kernel, Debian Stretch 9.8);
  • IP65 waterproofing;
  • No fan or motor heat dissipation structure;
  • 1-GHz Sitara™ ARM® Cortex®-A8 32‑Bit RISC Processor, 512MB DDR3, 4G eMMC;
  • PoE power supply or 110 / 220V AC power supply (110 / 220V AC power supply version use 4G upload LoRa data).
  • SX1301 digital baseband chip
  • Size: 125(+40) x 125 x 52 mm;
  • Emulates 49 LoRa demodulators and 1 FSK demodulator
  • 10 programmable parallel demodulation paths
  • Dynamic data-rate adaptation (ADR)
  • Automatic adaptive spread spectrum factor, SF7 to SF12 for each channel is optional
  • Maximum output: 20 ± 1dBm
  • Up to -139dBm sensitivity with SX1257 or SX1255 Tx/Rx front-end
  • Support for LoRaWAN Class A, Class C protocols
  • Through the unique heat conduction device to transfer heat to the aluminum housing, strengthen heat dissipation, make the operation more stable
  • -20°C to 70°C maximum operating temperature range
  • Working bands: Full band coverage corresponding to the working frequency option.



Technical Parameters


Electrical characteristics
