Parameter Min Typ. Max. Unit Condition Operation Condition Working voltage 1.8 3.3 3.7 V Temperature range -40 85 °C Current Consumption RX current 10.8 mA TX current 120 mA @20dBm Sleep current 1 uA RF Parameter Frequency range
848 868 888 MHz @868MHz Data Rate
1.2 300 Kbps FSK 0.018 37.5 Kbps LoRa Output Power -1 20 dBm Receiving sensitivity
-123 dBm @FSK data=1.2kbps, Fdev=10kHz -139 dBm @LoRa BW=125KHz_SF = 12_CR=4/5 Features
- Frequency Range:868 MHz （Customizable 137-1020 MHz）
- Sensitivity up to :-139dBm @Lora
- Maximum output power:20 dBm
- Low RX current：10.3 mA
- Sleep current< 1.5uA
- Data transfer rate:@FSK,1.2-300 Kbps
- @Lora, 0.018-37.5 Kbps
- Excellent blocking immunity
- Lora、FSK、GFSK Modulation mode
- Built-in ESD Protection
- 127 dB Dynamic Range RSSI
- Packet engine up to 256 bytes with FiFo and CRC
- Built-in temperature sensor and low battery indicator
- Operating Temperature Range：-40 ~ +85 °C
Applications
- Remote meter reading
- Industrial control
- Home automation remote sensing
- Toys control
- Sensor network
- Tire pressure monitoring
- Wireless PC peripherals
- Health monitoring
