372,43 TL + KDV
Stok Durumu:
Var
(23 Adet)
Toptan alın indirim fırsatlarını yakalayın!
Miktar
İndirim
5 - 9
%3
10 - 20
%6
Not
:
Aynı Gün Kargo
15’e kadar aynı gün kargo
Worldwide
Shipment
Next Day
Shipment
Kampanya
{{CMP.TITLE}}
{{CMP.DESCRIPTION}}
- Ürün Özellikleri
- İade ve Teslimat
- Ödeme Seçenekleri
- Yorumlar (0)
- Beni Ara
- Ek
-
RF Parameter Value Remark Working frequency 410~493 MHz - Transmitting power 22 dBm Max. Power (160mW) Receiving sensitivity -147 dBm - Air data rate 0.018k~300kbps - Test distance 6500m In open and clear air, with maximum power, 5dBi antenna gain, height of 2m Hardware Parameter Value Remark Size 14 * 20 mm Antenna type IPEX / Stamp hole Communication interface SPI Package SMD Electronic parameter Min. Typ. Max. Unit Condition Power supply 1.8 3.3 3.6 V Communication level 1.8 3.3 3.6 V Transmitting current 95 100 105 mA 22dBm（160mW） Receiving current 6 6.5 7 mA Sleep current 1 2 3 nA Operating temperature -40 20 85 ℃ Operating humidity 10 60 90 % Storage temperature -40 20 125 ℃
