585,60 TL + KDV
Stok Durumu:
Var
(43 Adet)
Toptan alın indirim fırsatlarını yakalayın!
Miktar
İndirim
5 - 9
%7
10 - 20
%15
Not
:
Aynı Gün Kargo
15’e kadar aynı gün kargo
Worldwide
Shipment
Next Day
Shipment
Kampanya
{{CMP.TITLE}}
{{CMP.DESCRIPTION}}
- Ürün Özellikleri
- İade ve Teslimat
- Ödeme Seçenekleri
- Yorumlar (0)
- Beni Ara
- Ek
-
Limit Parameters Main Parameters Performance Remarks Min. Max Power supply（V） 0 5.5 Voltage over 5.5V will cause permanentdamage to module Blocking power（dBm） - 10 Chances of burn is slim when modules areused in short distance Operating temperature（℃） -40 85 / Operating parameter Main Parameters Performance Remarks Min. Typ. Max. Operating voltage（V） 3.3 5 5.5 ≥5.0 V ensures output powerr Communication level（V） 3.3 For 5V TTL, it may be at risk of burningdown Operating temperature（℃） -40 - 85 Industrial design Operating frequency（MHz） 410.125 - 493.125 Support ISM band TX Current(mA) 610 Instant power consumption RX current（mA） 17 Sleep current（μA） 2 Software is shut down Max Tx power（dBm） 29.5 30 30.5 Receiving sensitivity（dBm） -146 -147 -148 Air data rate is 2.4kbps Air data rate（bps） 0.3k 2.4k 62.5k Controlled via user’s programming Main parameter Description Remarks Distance for reference 8km Test condition：clear and open area, antenna gain: 5dBi，antenna height: 2.5m，air data rate: 2.4kbps TX length 240 Byte Can be configured via command as 32/64/128/240 bytesper packet to transmit Buffer 1000 Byte Modulation LoRa Communication interface UART Package DIP Connector 1*7*2.54mm Size 24*43mm Antenna SMA-K 50 ohm impedance
