Out of stock
289.04 TL + VAT
Stock Status:
Off
Note
:
Same Day Cargo
Same day cargo until 12.30 o'clock
Worldwide
Shipment
Next Day
Shipment
Campaign
{{CMP.TITLE}}
{{CMP.DESCRIPTION}}
- Features
- Return and Delivery
- Payment Options
- Comments (0)
- Call Me
- How Will We Ship To You
- Ek
-
Parameter Min. Typ. Max. Unit Condition Operation Condition Working voltage 1.8 3.3 3.7 V Temperature range -40 25 85 ℃ Current Consumption RX current < 6.5 mA @TCXO Crystal TX current < 130 mA @868MHz Sleep current 1.9 uA OFF mode (SLEEP mode with cold start) All blocks off 2.3 uA SLEEP mode (SLEEP mode with warm start) Configuration retained 2.9 uA SLEEP mode (SLEEP mode with warm start) Configuration retained + RC64k 0.56 mA STDBY_RC mode ， RC13M, XOSC OFF 2.35 mA STDBY_XOSC mode ， XOSC ON RF Parameter Frequency range 848 868 888 MHz @868MHz Output power -15 22 dBm Receiving sensitivity -133 dBm @LoRa BW=125KHz_SF = 10_CR=4/5 Features
- Frequency Range：868 MHz（customizable150-960 MHz）
- Sensitivity：-148dBm @Lora
- Maximum output power：22 dBm（160mW）
- Industrial grade high precision crystal oscillator
- Lora,(G)FSK
- 256 bytes FiFo
- Data transfer rate：0.6-300 Kbps @FSK 0.018-62.5 Kbps @Lora,
Applications
- Industrial meter reading
- Parking lot sensor management
- Industrial automation
- Agricultural sensor
- Smart city
- Remote control
- Street lights
- Logistics management
- Environmental sensor
- Health products
- Security products
- Warehouse management
