Quad Band, Class10, GPRS Terminal with Python

Specifications - Mechanical
■ Dimensions: 107 x 64 x 33 mm,
■Weight: 135 grams.

Key Features
■ Quad-band EGSM 850 / 900 / 1800 /1900 MHz,
■ Embedded Python Version 1.5.2 ,
■ 4 GPIO or IIC Bus
■ RS232 ınterface (DB9-Female),
■ RJ11 / 6Pin for GPIOs

Product Features
■ Supported bands
 - 4 Bands GSM / GPRS : 850 / 900 / 1800 / 1900 MHz
■ SIM Access Profile,
■ Quad Band GPRS and EDGE class 33,
■ Input Voltage Level —>9 – 24VDC
■ Control via AT commands,
■ Serial port multiplexer 3GPP TS27.010,
■ SIM application Tool Kits 3GPP TS
■ Built in UDP/TCP/FTP/SMTP stack,
■ Extended temperature range: - 40°C to +85°C (Operational),
■ Status and Power Leds.

Interfaces
■ 4 GPIO or IIC Bus
■ RJ11 / 6Pin for GPIOs
■ D-type 9 pin RS-232 connector,
■ SMA female, 50 Ohm RF connector,
■ Power Socket (PWR, GND, RST),
■ On board SIM card holder(Push-Push Type),
