RAK7268C WisGate Edge Lite 2, 868MHz, EG95-E

Product Description

The RAK7268 WisGate Edge Lite 2 is a full 8-channel indoor gateway, based on the LoRaWAN protocol, with built-in Ethernet connectivity for a straightforward setup. Additionally, there is an onboard Wi-Fi setup (supporting 2.4 GHz Wi-Fi) that allows it to be easily configured via the default Wi-Fi AP mode. Moreover, the gateway supports LTE uplink communication connections (optional).

As with the other RAKwireless Industrial Gateways, it also supports MQTT Bridge mode, with the option for TLS authentication.

Power-over-Ethernet (PoE) is supported to serve cases where wall or ceiling mounting is required without the need to install additional power lines.

The open-source software for the management and configuration of this gateway device is based on OpenWRT. It has a built-in LoRa packet forwarder and a graphical user interface, allowing for a quick set-up without giving up the freedom of a fully customized solution.

RAK7268 also supports the MQTT Bridge function, can use the MQTT integrated to third-party platforms.

RAK7268 is especially suitable for small and medium-sized deployment scenarios in industry applications, saving the additional cost for server and R&D investment, and has the advantages of high execution efficiency.

Product Features

• Full LoRaWAN Stack support (V 1.0.3) with Semtech SX1302
• Supports 2.4 GHz Wi-Fi AP for configuration
• 100M Base-T Ethernet with PoE
• Multi back-haul with Ethernet, Wi-Fi, Cellular
• OpenWRT software supports Web UI for easy configuration and monitoring
• Can integrate with both private (ChirpStack) and public (TTN) network servers
• TF card for log backup and LoRa frame buffering (in case of backhaul failover)
• Built-in Network Server for easy deployment of applications and integration of gateways
• LTE Cat 4 network (optional)

Product Inclusion

• 1pc WisGate Edge Lite 2/2+
• 1pc LoRa antenna
• 1set Mounting screws
• 1set Anchors
• 1pc Power Adapter
