Introduction
The Raspberry Pi Pico 2 is a cutting-edge microcontroller that combines exceptional performance, security, and flexibility. Powered by the advanced RP2350 microcontroller, this next-generation board features dual Arm Cortex-M33 cores and Hazard3 RISC-V cores, delivering a significant boost in processing power and versatility. With comprehensive security features, including Arm TrustZone and hardware SHA-256 acceleration, the Raspberry Pi Pico 2 ensures robust protection for embedded systems. Its flexible interfacing capabilities, low power consumption, and extensive documentation make it a powerful solution for prototyping, education, and complex hardware integration.
Enhanced Performance
Equipped with dual Arm Cortex-M33 cores operating at up to 150MHz, Raspberry Pi Pico 2 offers a significant boost in processing power. The inclusion of the Hazard3 RISC-V cores provides developers the flexibility to experiment with different architectures.
Comprehensive Security
Built around Arm TrustZone for Cortex-M, the RP2350 microcontroller ensures robust security with features like signed boot support, hardware SHA-256 acceleration, and a true random number generator.
Flexible Interfacing
The second-generation Programmable I/O (PIO) subsystem and rich peripheral set allow for highly customizable interfacing with minimal CPU overhead, making it ideal for complex hardware integration.
Low Power Consumption
Manufactured on a 40nm process node, the RP2350 ensures low dynamic power consumption and offers a variety of low-power modes to support extended battery operation, making it suitable for portable and energy-sensitive applications.
Extensive Documentation
Comprehensive documentation and a polished MicroPython port ensure a smooth development experience, making Raspberry Pi Pico 2 accessible to both beginners and advanced users.
Specification
- Processor: Dual Arm Cortex-M33 cores @ 150MHz or dual Hazard3 RISC-V cores
- Memory: 520KB high-performance SRAM, supporting up to 16MB off-chip Flash memory via QSPI bus
Security:
- Arm TrustZone for Cortex-M
- 8KB on-chip OTP memory
- SHA-256 hardware acceleration
- True random number generator (TRNG)
Interfacing:
- 30 GPIO pins, including 4 analog inputs
- 2 UARTs, 2 SPI controllers, 2 I2C controllers
- 24 PWM channels
- USB 1.1 controller with host and device support
- 3 Programmable IO (PIO) blocks with 12 state machines
Power:
- On-chip programmable LDO for core voltage
- 2 on-chip PLLs for USB and core clocks
Documents
Shipping List
- Raspberry Pi Pico 2 × 1
