Parameters Min. Typ. Max. Unit Condition Working Condition Voltage range 3.3 5.0 6.5 V Operating Temperature -40 25 +85 ℃ Current Consumption Rx current <15 mA TTL level Tx current < 130 mA Sleep current < 200 uA RF Parameters Frequency range 414.92 433.92 453.92 MHz @433MHz 470.92 490.92 509.92 MHz @470MHz 849.92 868.92 888.92 MHz @868MHz 895.92 914.92 934.92 MHz @915MHz Data rate 91 656 17353 bps @LoRa Output power 4 20 +20 dBm Software level 7 adjustable Sensitivity -139 dBm @91bps
Features
- Transmission distance in the open area up to 5000 meters @ 91bps
- Frequency band: 433/470/868/915 MHz for option
- AES128 Data encryption
- MESH & Node working mode
- 40 channels
- LoRa modulation
- Interface: TTL/RS232/RS485
- Sensitivity: -139 dBm
- Max output power: 100mW（+20dBm）
- Working voltage: 3.3 ~ 6.5 V
- Working temperature: -40 ~ +85 °C
Applications
- Remote control
- Remote meter reading
- Industrial data collection
- Home automation telemetry
- Wireless data communication
- Access control system
