Hardware Specifications Cellular4GTDD-LTE:Band 34/38/39/40/41 Global frequency bandsFDD-LTE：Band 1/2/3/4/5/7/8/12/13/18/19/20/25/26/28/66 WCDMA:B1/2/4/5/6/8/19 GSM/GPRS/EDGE：B2/3/5/8 Antenna interface 2* Standard SMA-K interface (outer screw and inner hole) SIM card slot 2 *None-SIM Ethernet Interface Number of network ports Version with10 LAN ports：2*WAN/LAN+6*LAN+2*SFP; SFP: 1*WAN/LAN+1*LAN Network port specifications RJ45：10/100 /1000Mbps，IEEE 802.3 SFP：Gigabit optical port It has 1.5KV network isolation transformer protection Connecting TerminalV+，V- Built-in power reverse protection GND Ground terminal； Tx RS232 Rx RS232 A RS485 B RS485 DI1 Digital input port DO1 Digital output port Com Common teminal Wi-Fi6Antenna interface 2 * Standard RP-SMA-K interface (External screw and internal pins) MIMO 2×2 Standard and frequency band Support IEEE802.11b/g/n/ac/ax，2.4GHz&5.8G Wireless functionality AP / STA/ Relay / Bridge The rate of the theory 2976Mbps(5GHz:2402Mbps,2.4GHz:574Mbps) Secure encryption No encryption/mixed-psk/psk/psk2/psk2+ccmp Transmission distance Open outside / no obstruction, coverage radius up to 200 meters; Indoor office environment/barrier, coverage radius up to 40 meters Note: The measured rate is affected by the field environment, please take the measured rate as the standard Theoretical device capacity 2.4G+5.8G:256 Positioning Function Antenna interface 1 * Standard SMA-K interface (external screw and internal hole) Positioning criteria GPS Power Supply Specifications Adapter DC 12V/2.5A Power supply interface Power supply for industrial terminals with anti-polarity protection Scope of power supply DC 9-60V Serial Port RS485/RS232 Industrial terminal Baud rate（bps） 1,200,240,048,009,600,000,000,000,000,000,000,000,000,000 Data bit 7,8 Stop bit 1,2 Check bit NONE,ODD,EVEN Software Functions VPN PPTP、L2TP、IPSec、OpenVPN、GRE、VXLAN、Wireguard Physical Characteristics Hull Aluminum alloy shell, dustproof grade IP40 Size 118.0*96.0*48.7mm（L*W*H，Parts and antenna seats are not included） Way to install Guide rail installation, horizontal desktop placement EMC National standard 3B grade working temperature -40℃ ~ +75℃ Storage temperature -40℃～+85℃（No condensation） Working humidity 5%~95%（No condensation） Other Reset/Switch Screens Long press for 5-15 seconds to restore factory settings, and short press for 1-3 seconds to switch screens. USB Supports USB flash drives to expand storage space SD card slot Support SD card to expand storage space RTC RTC Ground protection Grounding screws Built-in watchdog Supports self-detection of equipment and self-recovery of faults OLED Display the basic information of the router
