SPECIFICATIONS
Item
Reference Scope
DC Power supply
7-24VDC
Power consumption
Low power consumption mode Standby:＜230uA;
Normal mode:10mA~30mA,Max:230-360mA.
Communication
Optional:GSM/GPRS/3G/4G/NB-IoT/Ethernet/LoRa
Protocols
Modbus RTU Over TCP, MQTT
SIM interface
Nano
Cellular Antenna
SMA Antenna interface, 50 Ohm
Serial Interfaces
Micro USB Port;
Digital output
OC output,1A 30V DC
Digital Input
NO or NC
Analog Inputs
0-5V or 4-20mA
Temp.&Hum Inputs
AM2301:Temperature range: -40°C to +80°C, Humidity Range: 0~100%RH
Temperature Input
DS18B20:Temperature range: -55°C to +125°C,±3% RH
Temperature range
-10-+60 °C
Humidity range
Relative humidity 95% (condensation free)
FEATURES
1. Can be used as a complete product or as a secondary development module;
2. Two working modes are available:
Normal mode: Real-time data transmission,Users can inquiry the real-time status;
Low power consumption mode: Ultra low power consumption(＜230uA);
3. Multiple communication methods:GSM,GPRS,3G,4G,NB-IoT,LoRa,Ethernet,etc;
4. Coverting DS18B20 temperature probe signal to cloud platform over cellular network;
5. Support configure parameters and query real-time data via SMS,software,cloud platform;
6. Up to 10 SMS Alert and dial numbers, can program to receive specified alarm message;
7. Support two different server centers,can set IP address or domain name ;
8. Support Modbus RTU over TCP and MQTT protocol;
9. Wide range power supply 7~24VDC with phase-reversal protection;
10. Using Nano sim card,support PIN code function;
11. Provide PCBA or waterproof enclosure,can be used outside.
