Electrical Specifications
Frequency Range
868MHz
Gain
10dBi
VSWR
<1.5
Input Impedance
500
Polarization
Vertical
Horizontal Half Power Angle
360°
Vertical Half Power Angle
32°
Front to Back Ratio
>15dB
Max Input Power
50W
Lightning Protection
DC Ground
Mechanical Specifications
Connector Type
N male
Working Temperature
-40°C~+65C -
Antenna Weight
620g
Pole Diameter
035~055mm
Size
020*1300mm
Rated Wind Velocity
210km/h
Cover Material
Fiberglass
Color
White
