RF Parameter Value Remark Working frequency 425~450.5 MHz Default: 433MHz
Transmitting power 30 dBm About 1W
Receiving sensitivity -147 dBm Air data rate: 2.4kbps
Air data rate 0.3k~9.6kbps Default: 2.4kbps
Test distance 8000 meter In open and clear air, with maximum power, 5dBi antenna gain, height of 2m,
air data rate: 2.4kbps
Hardware Parameter Value Remark Size 82 * 62 * 25 mm Antenna type SMA-K Communication interface RS232 / RS485 Baud rate: 1200~115200, default: 9600
Package DB-9 / Screwing Standard DB9 Hole/3.81 connecting terminal
Buffer 512 bytes buffer Automatically sub-packaging with 58 bytes per package
Electronic parameter Min. Typ. Max. Unit Condition Power supply 10 12 28 V Transmitting current 625 684 761 mA 30dBm（1W） stand-by current 27 29 32 mA Operating temperature -40 20 +85 ℃ Operating humidity
10 60 90 % Storage temperature -40 20 +125 ℃
