| Center Frequency | : | 1575.42±3MHz |
| Band Width | : | CF±5MHz |
| Polarization | : | RHCP |
| Gain | : | 5dBic(Zenith) |
| V.S.W.R | : | <1.5 |
| Impendance | : | 50Ω |
| Axial Ratio | : | 3dB(max) |
| Dimension | : | 25*25*4mm |
| Gain | : | 15±2dB |
| Noise Figure | : | <1.5 |
| Supply Voltage | : | 2.2~5V DC |
| Current Consumption | : | 5~12mA |
| V.S.W.R | : | <2.0 |
| Cable | : | 200 mm |
| Connector | : | IPEX or others |
| Operating Temperature | : | -40℃~+85℃ |
| Relative Humidity | : | Up to 75% |
| Vibration | : | 10 to 55Hz with 1.5mm amplitude 2hours |
| Environmentally Friendly | : | ROHS Compliant |
| Ürün Filtreleri | ||
|---|---|---|
| Barkod | : | 8690000008377 |
| Tedarikçi Ürün Kodu | : | YG-GPS-200MM-IPEX-25-25-4 |
