Raspberry Pi Compute Module 5 4 GB Ram with 16 GB eMMC

55 mm × 40 mm × 4.7 mm module

4 × M2.5 mounting holes

Broadcom BCM2712 quad-core 64-bit Arm Cortex-A76 (Armv8) SoC @ 2.4GHz

Memory options:

• 4GB LPDDR4-4267 SDRAM with ECC
• 16GB eMMC flash memory

Certified radio module containing:

• 2.4 GHz, 5.0 GHz IEEE 802.11 b/g/n/ac wireless
• Bluetooth 5.0, BLE
• On board electronic switch to select between PCB trace or external antenna

Gigabit Ethernet PHY supporting IEEE 1588

1 × PCIe x1 root complex, Gen 2 (5Gbps)

1 × USB 2.0 port (high speed)

2 × USB 3.0 ports, supporting simultaneous 5Gbps operation

Up to 30 × GPIO supporting either 1.8V or 3.3V signalling and peripheral options:

• Up to 5 × UART
• Up to 5 × I2C
• Up to 5 × SPI
• 1 × SDIO interface
• 1 × DPI (parallel RGB display)
• 1 × I2S
• Up to 4 × PWM channels
• Up to 3 × GPCLK outputs

2 × HDMI 2.0 ports (supports up to 4Kp60 on both ports simultaneously)

2 × 4-lane MIPI ports supporting both DSI (display port) and CSI-2 (camera port)

4Kp60 HEVC decoder

OpenGL ES 3.1 graphics, Vulkan 1.2
