uFeatures
ØObject distance or level detection without touch
ØUltra-wide-distance transmission up to line of sight of 10km
ØIP67 waterproof enclosure for harsh environment applications
ØBuilt-in 19000 mAh replaceable battery and work for 10 years
without replacement
ØEquipped with NFC for easy configuration
ØCompliant with standard LoRaWAN® gateways and network
servers
ØQuick and easy management with Milesight IoT Cloud solution
uApplications
ØWater level monitoring
ØFlood monitoring
ØLevel/depth monitoring in tanks
ØSnow level monitoring
ØSmart agriculture: fill level monitoring in grain, fertilizer or pellets silos
uSpecifications
WirelessTransmission | |
Technology | LoRaWAN® |
Frequency | CN470/IN865/RU864/EU868/US915/AU915/KR920/AS923-1&2&3&4 |
TxPower | 16dBm(868)/20dBm(915)/19dBm(470) |
Sensitivity | -137dBm@300bps |
Mode | OTAA/ABPClassA |
Measurement | |
Range&Accuracy | W050:0.3-5m,±1%FS W100:0.5-10m,±1%FS S050:0.3 -5m (SnowVersion),±1%FS C050: 0.25 - 5 m, ± (1+0.3%*S) cm, S=distance C100: 0.25-8m,±(1+0.3%*S)cm, S=distance |
Resolution | 1mm |
Operation | |
PowerOn&Off | NFC,PowerButton(Internal) |
Configuration | MobileApp(viaNFC)orPCsoftware(viaUSBType-C) |
PhysicalCharacteristics | |
PowerSupply | 19000mAhLi-SOCL2battery(ER34615) |
BatteryLife* | 10years(10mininterval) |
OperatingTemperature | W050/W100/S050:-30°Cto+65°C C050/C100:-15°Cto+60°C |
RelativeHumidity | 0%to80%(non-condensing) |
IngressProtection | IP67 |
Dimension | 156.1×71×69.5mm(6.1×2.8× 2.7 in) |
Installation | Pole,wallorDINRailMounting |
Approvals | |
Regulatory | CE,FCC,RoHS,LoRaWAN®Certified |
EMC | EN55032,EN55035 |
EMS | IEC 61000-4-2Level3,IEC61000-4-3Level2,IEC61000-4-8Level 4 |
RadioFrequency | FCCPart15B,FCCPart15.247,EN300330,EN301489-1/3, EN300220-1/2 |
Safety | EN62368-1 |
