uFeatures
ØOccupancy or motion detection based on passive infrared and Fresnel Lens
ØEasily to install with the convenient size
ØBuilt-in light sensor, combine PIR sensor to achieve triggers
ØUltra-wide-distance wireless transmission up to line of sight of 15 km
ØEquipped with NFC for one touch configuration, support card emulation mode
ØSupport Milesight LoRa D2D protocol to enable ultra-low latency and directly
control without gateway
ØFunction well with standard LoRaWAN® gateways and network servers
ØCompliant with Milesight IoT Cloud
- Specifications
WirelessTransmission | |
Technology | LoRaWAN®,LoRaD2D |
Frequency | CN470/IN865/RU864/EU868/US915/AU915/KR920/AS923 |
TxPower | 16dBm(868MHz)/22dBm(915MHz)/19dBm(470MHz) |
Sensitivity | -137dBm@300bps |
Mode | OTAA/ABPClassA |
Measurement | |
PIR | |
DetectionArea | 120°Horizontal,100°Vertical |
DetectionDistance | Maximum8m |
Light | |
Status | Bright/Dark(Determine 1-60000 luxasBright orDark accordingto custom threshold) |
Software | |
Configuration | NFC |
AdvancedFeature | LoRaD2DController |
PhysicalCharacteristics | |
PowerSupply | 1×1650mAhER14335Li-SOCl2Battery |
BatteryLife* | Around4years(30mininterval+30triggers per day) |
OperatingTemperature | -20°Cto+60°C |
RelativeHumidity | ≤90%(non-condensing) |
IngressProtection | IP30 |
Dimension | 50× 50×23.8mm (1.97×1.97×0.94in) |
Material | Anti-flamingPolycarbonate |
Color | White |
Installation | Ontheflatsurfaceswithscrewsor3Mtapes |
Approvals | |
Regulatory | CE,FCC,RoHS |
*Testedunderlaboratoryconditionsandforguidelinepurposesonly.
