Features
ØDetect the presence of liquids by a small water probe and based on the conductive principle
ØEmbedded with temperature and humidity sensors for environment monitoring
ØUltra-wide-distance transmission up to line of sight of 10km
ØIP67 UV-resistant and waterproof enclosure for harsh environment applications
ØBuilt-in 4000 mAh replaceable battery and works for 5 years without replacement
ØEquipped with NFC for easily configuration
ØCompliant with standard LoRaWAN® gateways and network servers
ØQuick and easy management with Milesight IoT Cloud solution
uSpecifications
WirelessTransmission | |
Technology | LoRaWAN® |
Frequency | CN470/IN865/RU864/EU868/US915/AU915/KR920/AS923 |
TxPower | 16dBm(868)/20dBm(915)/19dBm(470) |
Sensitivity | -147dBm@300bps |
Mode | OTAA/ABPClassA |
Measurement | |
LeakageDetection | |
TriggerCondition | Whenliquidlevelreaches5mm |
CableLength | 1.5m(customizable) |
Temperature | |
Range | -30°Cto+70°C |
Accuracy | 0°Cto+70°C(+/-0.3°C),-30°Cto0°C(+/-0.6°C) |
Resolution | 0.1°C |
Humidity | |
Range | 0%to100%RH |
Accuracy | 10%to90%RH(+/-3%),below10%andabove90%RH(+/-5%) |
Resolution | 0.5%RH |
Operation | |
PowerOn&Off | NFC,power button(Internal) |
Configuration | MobileAPP(via NFC)orPCsoftware(via USBType-C) |
PhysicalCharacteristics | |
PowerSupply | 1×4000 mAhER18505Li-SOCL2battery(extendableto 2batteries) |
BatteryLife* | >5years(10minintervalandalarmonceeveryday,SF10) |
OperatingTemperature | -30°Cto+70°C |
RelativeHumidity | 0%to100%(non-condensing) |
IngressProtection | IP67 |
Dimension | 105.6×85.3 ×27 mm(4.16 ×3.36 ×1.06 in) |
Installation | WallMounting |
