FEATURES
· Built-in MEMS accelerometer sensor to measure the 3-axis angles of any objects
· Flexible threshold condition settings, suitable for different kinds of applications
· Easy to install, suitable for various types of objects as trees, poles, grounds, etc.
· IP67 waterproof enclosure for outdoor applications and easy to clean
· Ultra-wide-distance wireless transmission up to line of sight of 15 km
· Equipped with NFC for one touch configuration, supports card emulation mode
· Function well with standard LoRaWAN® gateways and network servers
· Compliant with Milesight IoT Cloud
uSpecifications
WirelessTransmission | |
Technology | LoRaWAN® |
Frequency | CN470/IN865/RU864/EU868/US915/AU915/KR920/AS923-1&2&3&4 |
TxPower | 16dBm(868MHz)/22dBm(915MHz)/19dBm(470MHz) |
Sensitivity | -137dBm@300bps |
Mode | OTAA/ABPClassA |
Measurement | |
Axis | X,Y,Z |
Range | -90°~+90° |
Accuracy | ±1° |
Resolution | 0.01° |
Others | |
Configuration | NFCConfigurationvia MobileApp |
Button | 1×ResetButton(Internal) |
PhysicalCharacteristics | |
PowerSupply | 2×3500mAhER17505Li-SOCl2Batteries |
BatteryLife* | Over 5years(6triggersperhour) |
OperatingTemperature | -20°Cto+60°C |
RelativeHumidity | ≤95%(non-condensing) |
IngressProtection | IP67 |
Dimension | 111×62×33mm (4.37×2.44×1.30in) |
Material&Color | ABS,Black |
Installation | Ontheflatsurfaceswithscrews |
*Testedunderlaboratoryconditionsandforguidelinepurposesonly.
| Ürün Filtreleri | ||
|---|---|---|
| Barkod | : | 8690000024698 |
| Tedarikçi Ürün Kodu | : | EM310-TILT-868M |
