DRAGINO

LG308 Indoor LoRaWAN Gateway

Ürün Kodu : LG308-868-EC25-E
Yorumlar
Paylaş:
Fiyat Alarmı
20.197,44 TL + KDV

The LG308 is an open source LoRaWAN Pico Gateway. It lets you bridge LoRa wireless network to an IP network via WiFi, Ethernet, Or 3G/4G cellular via optional LTE module. The LoRa wireless allows users to send data and reach extremely long ranges at low data-rates.


The LG308 uses semtech packet forwarder and fully compatible with LoRaWAN protocol. It includes a SX1301 LoRa concentrator + 2 x SX1257, which provide 10 programmable parallel demodulation paths.

LG308 has pre-configured standard LoRaWAN frequency bands to use for different countries. User can also customized the frequency bands to use in their own LoRa network.

LG308 has optional built-in LoRaWAN server. System integrator can use it to integrate with their existing IoT Service without set up own LoRaWAN server or use 3rd party LoRaWAN service.

Features:

  • Open Source OpenWrt system
  • Managed by Web GUI, SSH via LAN or WiFi
  • Internet connection via LAN, WiFi, Or 3G/4G via optional LTE module
  • Emulates 49x LoRa demodulators
  • LoRaWAN Gateway
  • 10 programmable parallel demodulation paths



Applications:

  • Smart Buildings & Home Automation
  • Logistics and Supply Chain Management
  • Smart Metering
  • Smart Agriculture
  • Smart Cities
  • Smart Factory

Specifications:

LoRa Spec:

  • 1 x SX1301 + 2 x 1257 LoRa Tranceiver

General Specification:

  • 10M/100M RJ45 Ports x 2
  • 1 x 2.4G WiFi (802.11 bgn)
  • 1 x USB host port
  • 1 x Mini-PCIe Interface
  • Power Input: 12v, 1A

Cellular 4G LTE (optional):

  • Quectel EC25 LTE module ( Clink the link to find the right model for your region)
  • Micro SIM Slot
  • Internal 4G Antenna + External 4G Sticker Antenna.
  • Up to 100Mbps downlink and 50Mbps uplink data rates
  • Worldwide LTE,UMTS/HSPA+ and GSM/GPRS/EDGE coverage
  • MIMO technology meets demands for data rate and link reliability in modem wireless communication systems
